iBasso DC07Pro
Hi-Res Portable / Dongle 4.4mm Balanced/3.5mm Single-ended USB DAC & Headphone Amplifier / DAC Amp

100% PRODUK RESMI
100% PRODUK ORIGINAL
GARANSI RESMI 1 TAHUN

FEATURES
◉ Quad Cirrus Logic CS43131 Master HIFIT DAC Chips.
◉ THD+N reaches 0.000098%,
◉ 430mW+430mW@32ohm output power balanced.
◉ 0.76µV ultra low noise floor.
◉ Detachable cable design.
◉ OLED Screen
◉ Aluminum CNC case with tempered glass panels on both sides.
◉ Support of PCM up to 32bit/768kHz.
◉ Support of Native DSD up to 512x.
◉ 4.4mm balanced output and 3.5mm single-ended output.
◉ FPGA built-in and KDS Femtosecond oscillator.
◉ Dedicated UAC APP for Android devices, which allows adjustment of volume, channel balance, and digital filters.
◉ Works as a USB-DAC for Android smartphones & tablets, Mac, Windows, & Linux computers.
◉ Support of UAC2.0.

SPECIFICATIONS
•DAC Chipset: Quad Cirrus
Logic CS43131
•PCM: Up to 32bit/768kHz
•DSD: Native DSD 512x
•Weight: 23g
•Size: 59mm*23.5mm*12.5mm*

4.4mm Balanced Output:
•THD+N: -120.2dB (0.000098%)@1kHz 3000 Load
•Output Voltage:
2.8Vrms (Low Gain)
3.5Vrms (Mid Gain)
4Vrms (High Gain)
•Output Power:
510mW+510mW @160, THD+N•S/N: 134dBA
•Dynamic Range: 134dBA
•Crosstalk: 142dB
•Frequency Response: 10Hz-80kHz -0.5dB
•Noise Floor: 0.85μν

3.5mm Single-ended Output:
•THD+N:-116dB (0.00017%)@1kHz 3000 Load
•Output Voltage:
1.4Vrms (Low Gain)
1.73Vrms (Mid Gain)
2Vrms (High Gain)
•Output Power:
210mW+210mW @160, THD+N
•S/N: 129dBA
•Dynamic Range: 129dBA
•Crosstalk: 136dB
•Frequency Response: 10Hz-75kHz -0.5dB
•Noise Floor: 0.76μν
